Zhejiang Weide Electric Co., Ltd. is one of the leading manufacturers and suppliers of compact relay module in China. With abundant experience, we warmly welcome you to buy the newest compact relay module from our factory. All customized products are with high quality and low price. Contact us for free sample.
Product Details
Name: Compact relay module
Model: WDX-8PC-RY/D6
Ultra thin integration of Compact relay module: 4-channel integration, single mode group width of only 12.5mm, 35mm DIN rail installation, greatly saving cabinet space.
Compact relay module Coil voltage: DC 6V (model D6), standard industrial low-power input.
Contact specifications: 1 set of normally open (1NO), 5A 250VAC/5A 30VDC, resistive load 1250VA/150W.
Compact relay module Electrical isolation: 3500VAC withstand voltage between coil and contact, strong anti-interference, protecting PLC/controller.
Status indication: Each channel is equipped with LED indicator lights, making the action status clear at a glance.
Convenient wiring: Spring/screw type wiring, supporting 0.5-1.5mm ² cables, tool free quick wiring.
High reliability: Flame retardant PC shell (compliant with RoHS), working temperature * * -30 ℃~+70 ℃ * *, vibration resistance, long life.
Strong universality: compatible with NPN/PNP inputs, suitable for various PLCs, microcontrollers, and industrial computers.
WDX-4PC-PY/D6
|
Model Number |
WDX-4PC-PY/D6 |
|
Brand |
WDIR |
|
Contact capacity (resistive load) |
5A,250VAC-5A,30VDC |
|
Shell material |
Flame retardant and environmentally friendly PC+ROHS |
|
Maximum allowable power for contacts (resistive load) |
1250VA,150W |
|
Input Voltage |
24VDC |
|
Insulation Voltage |
3500V/S |
|
Card spring tension |
1000kgf/cm |
|
Wire Gauge |
0.5 – 1 mm² |
|
Maximum allowable voltage of contacts |
250VAC,110VDC(0.4) |
|
Maximum allowable current at the contact point |
5A(AC/DC) |
|
Usage environment |
-35℃–70℃ |
|
Conductor Size |
1.5 mm² / AWG 16 |
|
Length/Width/Height (mm) |
L85.1/H33.1/3.60 |
|
Attestation |
RoHS,CCC,ISO：9001,CE |
|
Characteristic |
WDIR, LOGO customizable |
|
Packing For Transport |
1pieces per box |
WDX-8PC-RY/D6
|
Model Number |
WDX-8PC-RY/D6 |
|
brand |
WDIR |
|
Contact capacity (resistive load) |
5A,250VAC-5A,30VDC |
|
Shell material |
Flame retardant and environmentally friendly PC+ROHS |
|
Maximum allowable power for contacts (resistive load) |
1250VA,150W |
|
input voltage |
24VDC |
|
insulation voltage |
3500V/S |
|
Card spring tension |
1000kgf/cm |
|
Wire Gauge |
0.5 – 1 mm² |
|
Maximum allowable voltage of contacts |
250VAC,110VDC(0.4) |
|
Maximum allowable current at the contact point |
5A(AC/DC) |
|
Usage environment |
-35℃–70℃ |
|
Conductor Size |
1.5 mm² / AWG 16 |
|
Length/Width/Height (mm) |
L85.1/H60.001/3.60 |
|
attestation |
RoHS,CCC,ISO：9001,CE |
|
characteristic |
WDIR, LOGO customizable |
|
packing for transport |
1pieces per box |
WDX-4PC-RY
|
Model Number |
WDX-4PC-RY |
|
brand |
WDIR |
|
Contact capacity (resistive load) |
5A,250VAC-5A,30VDC |
|
Shell material |
Flame retardant and environmentally friendly PC+ROHS |
|
Maximum allowable power for contacts (resistive load) |
1250VA,150W |
|
input voltage |
24VDC |
|
insulation voltage |
3500V/S |
|
screw torque |
0.8N/1.2NM |
|
Screw size |
M3 |
|
Maximum allowable voltage of contacts |
250VAC,110VDC(0.4) |
|
Maximum allowable current at the contact point |
5A(AC/DC) |
|
Usage environment |
-35℃–70℃ |
|
Conductor Size |
1.5 mm² / AWG 16 |
|
Length/Width/Height (mm) |
L70.81/H32.4 |
|
attestation |
RoHS,CCC,ISO：9001,CE |
|
characteristic |
WDIR, LOGO customizable |
|
packing for transport |
1pieces per box |
