Zhejiang Weide Electric Co., Ltd. is one of the leading manufacturers and suppliers of flat head button switch in China. With abundant experience, we warmly welcome you to buy the newest flat head button switch from our factory. All customized products are with high quality and low price. Contact us for free sample.
Product advantages
Name: flat head button switch
Model: WD-A7-P10F/WD-A7-P01F/WD-A7-P11F/WD-A7-P20F WD-A7-P02F/WD-A7-P21F/WD-A7-P12F/WD-A7-P22F WD-A7-P10Z/WD-A7-P01Z/WD-A7-P11Z/WD-A7-P20Z WD-A7-P02Z/WD-A7-P21Z/WD-A7-P12Z/WD-A7-P22Z
Flat head button swicth has two practical working modes: self resetting triggered by pressing and automatic rebound when released, suitable for instantaneous signal triggering to avoid misoperation.
Self locking mode: Hold the state after pressing, reset only after pressing again, suitable for scenarios that require continuous on/off without the need for continuous pressing.
Flat head button swicth is designed with flat plastic structure and has the characteristics of insulation, flame retardancy, corrosion resistance and aging resistance, which is very suitable for electrical cabinets and equipment panels. Its contact structure is designed modularly, so it can be flexibly matched with normally open and normally closed contacts to meet various circuit requirements.
In addition, flat head button also has stable contact performance, a long mechanical service life, and is compatible with standard mounting holes, making it very suitable for assembly and use in large-scale industrial equipment.
Main purpose
Plastic flat head button is widely used for industrial equipment start-stop control. The momentary type supports jog control, while the latching type is suitable for power switching and mode selection. It applies to electrical control cabinets and PLC signal input for remote device operation. Ideal for automated production lines, machine tools and packaging equipment, it serves as a basic manual control component for low-voltage power distribution and circuit switching.
Operating mechanism code
|
Head code |
Field description |
Head code |
Field description |
|
P |
Plastic flat head button |
JP |
Aluminum cap round flat head button |
|
X |
Plastic second gear knob |
JX |
Aluminum cap second gear knob |
|
XS |
Plastic third gear knob |
JXS |
Aluminum cap third gear knob |
|
JY |
Aluminum cap second gear key button |
JYS |
Aluminum cap third gear key button |
|
M |
Plastic mushroom-shaped head button |
JM |
Aluminum cap mushroom-shaped head button |
|
ZS |
Plastic emergency stop button |
R |
Plastic double-key button |
Color
|
Color |
1 |
2 |
3 |
4 |
5 |
6 |
|
Contact Color |
White:W |
black :K |
green :G |
red :R |
yellow :Y |
blue:B |
Contact type
|
Code |
1 |
2 |
3 |
4 |
5 |
6 |
|
Contact code |
NO |
NC |
2NO |
2NC |
1NO+1NC |
2NO+2NC |
Voltage
|
Voltage |
AC/DC6V |
AC/DC12V |
AC/DC24V |
AC/DC36V |
AC/DC48V |
AC/DC110V |
AC/DC220V |
AC220V |
AC380V |
|
Code |
21 |
22 |
23 |
24 |
25 |
26 |
28 |
31 |
32 |
Plastic flat-head button
|
Product Name |
Plastic flat head button self resetting/self-locking |
|
Enterprise code |
WD-A7-P10F/WD-A7-P01F/WD-A7-P11F/WD-A7-P20F WD-A7-P02F/WD-A7-P21F/WD-A7-P12F/WD-A7-P22F WD-A7-P10Z/WD-A7-P01Z/WD-A7-P11Z/WD-A7-P20Z WD-A7-P02Z/WD-A7-P21Z/WD-A7-P12Z/WD-A7-P22Z |
|
Head code |
Plastic flat head |
|
Contact |
1NO / 1NC / 1NO1NC / 2NO / 2NC / 2NO1NC / 1NO2NC / 2NO2NC |
|
Operationtype code |
F-Momentary Z-Latching |
|
Color |
Red/green/blue/yellow/white |
|
Colorcutout size |
22mm |
|
Voltage |
6V-380V |
|
Material |
PVC flame retardant shell |
|
PVC flame retardant shell |
10A |
|
Waterproof rating |
IP65 |
Plastic flat head with indicator light
|
Product Name |
Plastic flat head button self resetting/self-locking/with indicator light |
|
Enterprise code |
WD-A7-P10F-D/WD-A7-P01F-D/WD-A7-P11F-D/WD-A7-P20F-D WD-A7-P02F-D/WD-A7-P21F-D/WD-A7-P12F-D/WD-A7-P22F-D WD-A7-P10Z-D/WD-A7-P01Z-D/WD-A7-P11Z-D/WD-A7-P20Z-D WD-A7-P02Z-D/WD-A7-P21Z-D/WD-A7-P12Z-D/WD-A7-P22Z-D |
|
Head code |
Plastic flat head with indicator light |
|
Contact |
1NO / 1NC / 1NO1NC / 2NO / 2NC / 2NO1NC / 1NO2NC / 2NO2NC |
|
Operationtype code |
F-Momentary Z-Latching |
|
Color |
Red/green/blue/yellow/white |
|
Colorcutout size |
22mm |
|
Voltage |
6V-380V |
|
Material |
PVC flame retardant shell |
|
PVC flame retardant shell |
10A |
|
Waterproof rating |
IP65 |
Aluminum alloy flat-head button
|
Product Name |
Aluminum alloy flat head button self resetting/self-locking |
|
Enterprise code |
WD-A7-JP10F/WD-A7-JP01F/WD-A7-JP11F/WD-A7-JP20F WD-A7-JP02F/WD-A7-JP21F/WD-A7-PJ12F/WD-A7-JP22F WD-A7-JP10Z/WD-A7-JP01Z/WD-A7-JP11Z/WD-A7-JP20Z WD-A7-JP02Z/WD-A7-JP21Z/WD-A7-JP12Z/WD-A7-JP22Z |
|
Head code |
Aluminum alloy flat head |
|
Contact |
1NO / 1NC / 1NO1NC / 2NO / 2NC / 2NO1NC / 1NO2NC / 2NO2NC |
|
Operationtype code |
F-Momentary Z-Latching |
|
Color |
Red/green/blue/yellow/white |
|
Colorcutout size |
22mm |
|
Voltage |
6V-380V |
|
Material |
PVC flame retardant shell |
|
PVC flame retardant shell |
10A |
|
Waterproof rating |
IP65 |
Aluminum alloy head button with indicator light
|
Product Name |
Aluminum alloy flat head button self resetting/self-locking/with indicator light |
|
Enterprise code |
WD-A7-P10F-/WD-A7-P01F-D/WD-A7-P11F-D/WD-A7-P20F-D WD-A7-P02F-D/WD-A7-P21F-D/WD-A7-P12F-D/WD-A7-P22F-D WD-A7-P10Z-D/WD-A7-P01Z-D/WD-A7-P11Z-D/WD-A7-P20Z-D WD-A7-P02Z-D/WD-A7-P21Z-D/WD-A7-P12Z-D/WD-A7-P22Z-D |
|
Head code |
Aluminum alloy head button with indicator light |
|
Contact |
1NO / 1NC / 1NO1NC / 2NO / 2NC / 2NO1NC / 1NO2NC / 2NO2NC |
|
Operationtype code |
F-Momentary Z-Latching |
|
Color |
Red/green/blue/yellow/white |
|
Colorcutout size |
22mm |
|
Voltage |
6V-380V |
|
Material |
PVC flame retardant shell |
|
PVC flame retardant shell |
10A |
|
Waterproof rating |
IP65 |
